WhisperPower WPC 12 V / 2000 VA – 100 A / 230V / 50Hz

Name: WhisperPower WPC 12 V / 2000 VA – 100 A / 230V / 50Hz
Brand: WHISPERPOWER
SKU: WPP-60201001
Price: 2061371 HUF

Price: 2 061 371 Ft
without VAT: 1 623 127 Ft+VAT (438 244 Ft)

Manufacturer:

WHISPERPOWER

Manufacturer Article number:

60201001

Warranty period :

Fogyasztói garancia: Jogszabály szerint ársávos! Cég, E.V: 1 év

Üzembe helyezés, üzemben tartás :

A termék nem megfelelő beszerelése, telepítése garanciavesztéssel jár! Ezért adott esetben fordulj szakemberhez!

pcs

Main warehouse

Out of stock

External warehouse

In stock

Delivery time approx: 1-2 Weeks!

Current (A):

100

Article number:

WPP-60201001

Nominal battery voltage :

12 VDC

Volt-Ampere :

Folyamatos: 2000, Max: 6000

Website:

https://www.whisperpower.com/wpc-12-v-2000-va-100-...

Weight:

25 kg/pcs

TECHNICAL SPECIFICATIONS
Nominal battery voltage	12 VDC
Continuous power @ 25°C	2000 VA
Power 30 min. @ 25°C	2000 VA
Power 5 sec. @ 25°C	6000 VA
Maximum load	Up to short-circuit (fully protected)
Maximum a-symmetric load	Up to continuous power
Load detection (stand-by)	2 to 25 W (AES) Automatic Enable System
Power factor	0.1 - 1
Efficiency (@ full load)	93 %
Consumption OFF / Stand-by / ON	1.4 W / 1.6 W / 9 W
Output voltage	Pure sine wave 230 VAC (+/- 2%)
Output frequency	50 Hz / 60 Hz (1) +/- 0.05% (crystal controlled)
Harmonic distortion (voltage)	<2% THD
Overload and short-circuit protection	Automatic disconnection with 3 time restart attempt
Overheat protection	Warning before shut-off with automatic restart

BATTERY CHARGER SPECIFICATIONS
Charge Characteristic	6-step Bulk - Absorption - Floating - Equalization - reduced floating - periodic absorption. Number of steps, thresholds and return amps are completely adjustable.
Maximum charging current	100 A
Temperature compensation	With Whisper temperature sensor WPC-BTS
Power Factor Correction (PFC)	EN 61000-3-2
Input voltage range	150 to 250 VAC
Input frequency range	45 to 65 Hz
Input current max. (transfer relay) / Output current max.	30 A / 50 A
Transfer time	<15 ms

MAIN SPECIFICATIONS
Weight	25 kg
Dimension H x W x D [mm]	510 x 330 x 150 mm
Protection degree	IP21
Color	RAL 9003
Conformity	Directive EMC 2004/108/EC : EN 61000-6-1, EN 61000-6-3, EN 55014, EN 55022, EN 61000-3-2, 62040-2. Low voltage directive 2006/95/EC : EN 62040-1-1, EN 50091-2, EN 60950-1
Operating temperature range	-20..+40°C, derating to 55°C
Relative humidity (operational)	95% without condensation
Ventilation	Forced from 45°C
Warranty	2 years
Acoustic level	<40 dB / <45 dB (without / with ventilation)
