WhisperPower Whisper Solar Flex 100 TC - Top Class 110,9 x 54,6 cm

Name: WhisperPower Whisper Solar Flex 100 TC - Top Class 110,9 x 54,6 cm
Brand: WHISPERPOWER
SKU: WPP-60110437

Manufacturer:

WHISPERPOWER

Manufacturer Article number:

60110437

Warranty period :

Fogyasztói garancia: Jogszabály szerint ársávos! Cég, E.V: 1 év

Üzembe helyezés, üzemben tartás :

A termék nem megfelelő beszerelése, telepítése garanciavesztéssel jár! Ezért adott esetben fordulj szakemberhez!

Main warehouse

Out of stock

External warehouse

In stock

Delivery time approx: 1-2 Weeks!

Discover the Whisper Solar Flex 100 TC, our advanced all-purpose solar module. These solar panels are the pinnacle of flexibility and efficiency in solar technology. Weighing just 2.2 kg/m2 and under 2 mm thick, they are incredibly lightweight and adaptable, ideal for diverse settings from boats to remote installations.

Details

WhisperPower Whisper Solar Flex 100 TC - Top Class 110,9 x 54,6 cm

Fully waterproof and saltwater resistant, each module is built to last and certified under IEC 61215, IEC 61730, and IEC 61701 standards. Integrated bypass diodes reduce power losses due to shading, ensuring consistent energy output. Compatible with batteries ranging from 5 to 48 volts, both lead-acid and lithium, and proudly made in Europe, WhisperSolar Flex represents the next step in sustainable energy solutions.

The most efficient Flexible, powerful and robust solar panel on the market
Flexible and lightweight (2.2 kg/m2)
Completely waterproof and resistant to salt water
Thin (less than 2 mm)
Integrated bypass diodes to minimise output losses associated with partial shading
Adaptable to any battery: from 5 to 48 volt, lead-acid or lithium
All-purpose solar module
IEC 61215, IEC 61730 and IEC 61701 certified

Data

Article number:

WPP-60110437

Power (W):

104

Website:

https://www.whisperpower.com/whispersolar-flex-104...

Weight:

1.4 kg/db

Technical specification

ARTICLE NUMBER
60110437	WP-Solar Flex 100 TC

DIMENSIONS & WEIGHT
Weight [kg]	1.40
Length Y [mm]	1109
Width X [mm]	546
Thickness [mm]	2

MAIN SPECIFICATIONS
Maximum power [W]	104
Max power Voltage Vmp [V]	18.2
Max power Current Imp [A]	5.7
Open circuit voltage Voc [V]	21.8
Short circuit current Isc [A]	6.0
NOCT [°C]	45 ± 2
Operating temperature [°C]	-40/+85
Temp. coeff. Pmax [ %/°C ]	-0.38
Temp. coeff. Voc [ %/°C ]	-0.27
Temp. coeff. Isc [ %/°C ]	0.05
Maximum system voltage [V]	1000 V
Maximum reverse current [A]	12 A
Safety class	A

MECHANICAL SPECIFICATIONS
Columns x Rows (cells n°)	4 x 8 (32)
