WhisperPower MC 12-24 VDC 10 A
WhisperPower MC 12-24 VDC 10 A
Price: 60 780 Ft
without VAT: 47 859 Ft+VAT (12 922 Ft)
  1. DC - DC Converters
  1. Energy supply
  2. WhisperPower
  3. Battery charging
  4. DC - DC Converters

WhisperPower MC 12-24 VDC 10 A

Article No.:
WPP-60110017
WhisperPower MC 12-24 VDC 10 A
Price: 60 780 Ft
without VAT: 47 859 Ft+VAT (12 922 Ft)
Manufacturer:
WHISPERPOWER
Manufacturer Article number:
60110017
Warranty period :
Fogyasztói garancia: Jogszabály szerint ársávos! Cég, E.V: 1 év
Üzembe helyezés, üzemben tartás :
A termék nem megfelelő beszerelése, telepítése garanciavesztéssel jár! Ezért adott esetben fordulj szakemberhez!
pcs
Main warehouse
Out of stock
External warehouse
In stock
Delivery time approx: 1-2 Weeks!

DC-DC step-up converter MC 12-24 VDC 10 A with common negative. Provides a stable 24 VDC to devices while operating on a 12V battery. The Switched Mode technology ensures minimal energy loss and high output. Fully protected against overload and high ambient temperatures. Incompatible for parallel setup.

Csomagajánlatok
  • Details
  • Info
  • Technical specification
  • Download User Manual
Details

WhisperPower MC 12-24 VDC 10 A

DC-DC step-up converter MC 12-24 VDC 10 A with common negative. Provides a stable 24 VDC to devices while operating on a 12V battery. The Switched Mode technology ensures minimal energy loss and high output. Fully protected against overload and high ambient temperatures. Incompatible for parallel setup.

  • Voltage step up and stabilization
  • Minimal energy loss thanks to Switched Mode technology (>90% efficiency)
  • High quality industrial design for high reliability and longer life cycle
  • Silent - no humming, only temperature controlled fans for cooling
  • No interference with radios, VHF or other sensitive equipment
  • Compact, fast and plug-and-play
  • Excellent price - performance ratio
Info
Output voltage (DCV):
12
Current (A):
10
Article number:
WPP-60110017
Website:
https://www.whisperpower.com/wp-mc-12-24-10
Weight:
360 g/pcs
Technical specification
ARTICLE NUMBER
60110017 MC 12-24 VDC 10 A
DIMENSIONS & WEIGHT
Length x width x height, mm (in.) 50 x 126 x 88 (2 x 5 x 3.5)
Weight, kg (lb.) 0.36 (0.8)
TECHNICAL SPECIFICATIONS
Converter type voltage step up and stabilization
INPUT
Nominal input voltage 12 VDC
Input range, specifications met 9 .. 18 VDC
Input range, no defects 0 .. 18 VDC
OUTPUT
Nominal output voltage 25 VDC
Voltage adjustable no
Output accuracy 3%
Ripple, peak output voltage 3%
maximum power output 300 W
continuous output power 250 W
Maximum output current 12 A
Continuous output current at 40 °C up to 10 A
GENERAL
efficiency >93%
consumption no load <5 mA
Ambient operating temperature -10°C .. +40°C
Storage temperature -25° .. +85°C
Relative humidity in use up to 95%, non-condensing
Galvanic isolation Common negative
Cooling convectional
PROTECTIONS
Current / short circuit Yes / fuse
Overheating, shut down no
MECHANICAL SPECIFICATIONS
Faston in / off, max thread thickness 6 mm²
Mounting holes dia 4 mm, rh 58 × 118
International Protection rating IP20
Housing frame 5
Housing material Alu / ABS
Housing colour RAL 9011 graphite black
Meets the following Standards EN61000-6-3 (EN55022), EN61000-6-2 (EN61000-2/3/4, EN61000-4-3), LVD 2006/95/EC (EN60335-1), Automotive EMC 2004/104/EC, RoHS 2011/65/EU Note: The above specifications are subject to change without prior notice.
Download User Manual


PDF Download
