- Dimensions: 17.5 x 14.2 x 5.5 cm
- Weight: 414 g
- Operating temperature range: -15°C to 55°C
- Waterproof rating: IPX7
- Compass safe distance: 40 cm
- Operating voltage: 9.6 - 31.2 Vdc
- Current drain: 12Vdc: < 400 mA; 24Vdc: < 250 mA
- Antenna connector: S0-239 (50 Ω)
- GPS refresh rate: 1 Hz
- Max antenna gain: 9 dB
- Transmitter power: 5 W
- NMEA 2000 LEN: 2
Garmin AIS™ 800 Blackbox Transceiver
Manufacturer:
GARMIN
Manufacturer Article number:
010-02087-00
Warranty period :
Fogyasztói garancia: Jogszabály szerint ársávos! Cég, E.V: 1 év
Üzembe helyezés, üzemben tartás :
A termék nem megfelelő beszerelése, telepítése garanciavesztéssel jár! Ezért adott esetben kérnénk forduljon szakemberhez!
Main warehouse
Out of stock
External warehouse
In stock
Delivery time approx: 1-2 Weeks!
Increase your situational awareness and confidence on the water with the Garmin AIS 800 transceiver. It has 5 watts of transmit power and provides faster position reporting than ever before.
Bundle offers
Garmin AIS™ 800 Blackbox Transceiver
- Easy-to-use, reliable communication transmits your vessel information to other AIS receivers in your area while receiving AIS target data
- 5 watts of transmit power with Class B/SO provides faster positioning reporting than ever before1
- Built-in GPS with connector for optional external antenna
- NMEA 2000® connectivity for easy integration with compatible chartplotters and multifunction displays
- Internal VHF antenna splitter allows VHF and AIS to share a single antenna
Increase your situational awareness and confidence on the water with the Garmin AIS 800 transceiver. It has 5 watts of transmit power and provides faster position reporting than ever before.1 It transmits your vessel information to other AIS receivers in your area while it receives their AIS target data. Garmin AIS 800 has an internal VHF antenna splitter, which allows the VHF and AIS to share a single antenna. It includes a built-in GPS (with connector for optional external antenna) and integrates seamlessly into the Garmin on-board system. The transceiver features NMEA 0183/2000® connectivity for easy integration with compatible chartplotters and multifunction displays. And it’s all packed into an easy-to-install black box unit with a small footprint.
1When cruising above 14 knots.
In the box:
- AIS 800
- NMEA 2000 T-connector
- NMEA 2000 drop cable (2 metres)
- VHF antenna extension (1.2 metres)
- USB adapter cable
- Power cable
- Mounting hardware
- Documentation
Input voltage (DCV):
9/32
Network Protocol:
NMEA2000
GPS:
Igen
Waterproof:
Igen
Navigation category:
VHF, AIS
Water resistance rating:
ipx7
Weight:
414 g/db
