Garmin Fusion® EL Series 6.5" 80-Watt Classic Black Marine Speaker (Pair)

Bundle offers

• Details
• Data
• Technical specification
• Download User manual

Details

Garmin Fusion® EL Series 6.5" 80-Watt Classic Black Marine Speaker (Pair)

Enjoy quality audio to enhance your boating experience with the EL Series speakers from Fusion.

  The injection-molded polypropylene cone provides clean, clear audio reproduction.

  The shallow basket design provides increased versatility during installation.

  The speakers are available in a 6.5” design with a classic style grille.

  Salt fog resistant and UV stable design for the harsh marine environment.



DESIGNED AND ENGINEERED FOR THE MARINE ENVIRONMENT

The EL Series speakers have an IP65 rating for protection against dust and water ingress and have been tested to a high level of protection against salt fog and UV.



DESIGNED TO COMPLY WITH ISO12216

Tested to international standards for pressure and water ingress, the EL Series speakers are designed and built for superior quality and robustness.



QUALITY MATERIALS AND ACOUSTIC ENGINEERING

The EL Series speakers incorporate high-quality materials and marine-specific design elements, ensuring they look and sound great on the water.

Engineered for quality acoustics.

INJECTION-MOLDED POLYPROPYLENE (IMPP) CONE

A translucent, water-resistant IMPP cone improves the robustness and durability of these classic marine speakers, allowing for clean, clear audio reproduction.

LIGHTWEIGHT VOICE COIL

The lightweight design allows for higher sensitivity, resulting in increased power and efficiency to deliver an enhanced audio experience.

OPEN BASKET CONSTRUCTION

The optimized open back design allows for extended power handling and versatile mounting options with reduced mounting depth.



In the box:

• One pair of speakers (based on what you select)
• 12 Phillips stainless steel mounting screws (4.2 mm x 25.4 mm (8 gauge x 1”))
• Two 20 ft (6 meter) speaker cables
• Documentation



Data

Power (W):

80

Number of inputs:

1

Colour:

Fekete

Waterproof:

Igen

Speaker size:

6.5"

Entertainment electronics:

Audio

Website:

https://www.garmin.com/en-US/p/622594/pn/010-02080...

Weight:

1.42 kg/db

Technical specification

General

Physical dimensions (Diameter x Depth)	6.93” x 2.26” (176 x 57.5 mm)
Water and dust rating	IP65
Configuration	Full range
Speaker size	6.5"
Peak power (Watts)	80 W
RMS power (Watts)	20 W
Sensitivity (1 W / 1 m)	88 dB
Frequency response	45 Hz-16 kHz
Nominal impedance	4 ohms
Recommended amplifier power (RMS)	20-40 W/Ch
Operating temperature range	32° to 122° F (0° to 50° C)
Voice coil diameter	0.79"
Cone material	Polypropylene cone with cloth surround
Compass-safe distance	100" (254 cm)
Warranty	1 year

Mounting Dimensions

Mounting diameter clearance	5.12" (130 mm)
Mounting depth clearance	1.69" (43 mm)
