General
| Physical dimensions (Diameter x Depth) | 6.93” x 2.26” (176 x 57.5 mm) |
| Water and dust rating | IP65 |
| Configuration | Full range |
| Speaker size | 6.5" |
| Peak power (Watts) | 80 W |
| RMS power (Watts) | 20 W |
| Sensitivity (1 W / 1 m) | 88 dB |
| Frequency response | 45 Hz-16 kHz |
| Nominal impedance | 4 ohms |
| Recommended amplifier power (RMS) | 20-40 W/Ch |
| Operating temperature range | 32° to 122° F (0° to 50° C) |
| Voice coil diameter | 0.79" |
| Cone material | Polypropylene cone with cloth surround |
| Compass-safe distance | 100" (254 cm) |
| Warranty | 1 year |
Mounting Dimensions
| Mounting diameter clearance | 5.12" (130 mm) |
| Mounting depth clearance | 1.69" (43 mm) |
