B&G H5000 Analogue Expansion

B&G H5000 Analogue Expansion

Manufacturer:

B&G

Manufacturer Article number:

000-11725-001

Warranty period :

Fogyasztói garancia: Jogszabály szerint ársávos! Cég, E.V: 1 év

Main warehouse

Out of stock

External warehouse

In stock

Delivery time approx: 1-2 Weeks!

Allows expansion of an H5000 system to include additional analogue and pulse signals from compatible 3rd party sensors. H5000 provides options for these inputs to be assigned to a known function type or to be set up as a custom input with name defined by the user.

B&G H5000 Analogue Expansion

Interface to allow expansion of an H5000 system to include analogue and pulse signals from compatible 3rd party sensors. H5000 allows these inputs to be assigned to a known function type or to be set up as a custom input with name defined by the user.

Key Features

6x Analogue input ports
2x Pulse input ports
Support for wide range of sensors including: Speed, Wind, Rudder, Mast Rotation
Configuration via H5000 CPU web browser
Industry standard compatible CAN network

0.4m Micro-C cable, metal
Micro-C T-piece, metal

Article number:

BG-000-11725-001

IP rating:

IP66

Website:

https://www.bandg.com/en-eu/bg/series/h5000/h5000-...

Weight:

170 g/pcs

Technical specification

Category	Details
Connectivity
NMEA 2000 Connectivity	1 x NMEA2000 Micro-C port, 1 LEN
Approvals
Approvals Compliance	IEC/EN 60945
Electrical
Power Consumption (typical)	0.6 W
Recommended Fuse Rating	5 A
Supply Voltage	12 V DC (10-16 V DC)
Environment
Operating Temperature Range	-10 to +55ºC (+14 to 131ºF)
Waterproof Rating	IP66
Physical
Dimensions (W x H x D)	61 x 131 x 45 mm (2.4 x 5.2 x 1.8")
Weight	0.17 kg (0.37 lbs)
Other
Interface	via Webserver on CPU
